EOS App Module NA for Remote Sauna Control
- Free USA Shipping On Many Items
- Full Warranty
- Secure Checkout
- Authorized Dealer
Control and Monitor Your Sauna from a Mobile Device
The EOS App Module NA connects a compatible EOS sauna control system to the EOS Spa Control App, allowing supported sauna functions to be monitored and adjusted from an Apple iOS or Android mobile device.
The compact module connects to the EOS sauna bus and to a router using a standard Ethernet cable. Once configured, the app can display current operating information and provide access to supported temperature, heating-time, humidity, lighting, and other connected control functions.
Add EOS Spa Control App Connectivity to a Compatible System
The EOS App Module NA is an extension module rather than a stand-alone sauna controller. It communicates with an approved EOS control unit through the pre-mounted sauna bus cable and connects to the local network through a wired RJ45 Ethernet connection.
The EOS Spa Control App automatically identifies the paired control system and adjusts the mobile interface to the available sauna, humid, steam, infrared, lighting, and accessory functions supported by that installation.
- Brand
- EOS
- Model
- APP MODULE NA
- SKU
- 14-949081
- Product type
- Remote-connectivity extension module
- Mobile platforms
- Apple iOS and Android
- Network connection
- Wired Ethernet
- Control connection
- EOS sauna bus
- Separate power supply
- Not required
Convenient Remote Access with Secure System Communication
Available app functions are determined by the paired EOS control, installed sensors, connected outputs, cabin type, and configured accessories.
Control from a Mobile Device
Access supported sauna controls through the EOS Spa Control App from an internet-connected Apple iOS or Android device.
Monitor Sauna Operation
Check supported information such as current temperature, target temperature, selected profile, and remaining heating time.
Customizable Presets
Save and select up to four customizable profiles for frequently used sauna settings supported by the connected system.
Pre-Mounted Sauna Bus Cable
The compact module includes a pre-mounted EOS sauna bus cable for connection to a compatible control relay box.
Automatic Firmware Updates
The module supports automatic firmware updating to help maintain current functionality and system communication.
No Separate Power Supply
The module receives 24V DC operating power through the EOS sauna bus connection and does not use a separate power adapter.
Dynamic IP Support
The module uses DHCP and IPv4 for variable IP-address assignment on a compatible local network.
Connection Indicators
Integrated LEDs provide visual feedback for pairing, network connection, and network activity.
North American Certification
The North American module is identified by EOS as UL certified for approved applications.
Verify the Control Model and Firmware Before Ordering
The EOS App Module NA is intended for selected North American EOS control systems. Compatibility requires both the correct control model and a supported firmware version.
Compatible Control Families
- EOS EmoTec D USA and CAN
- EOS EmoTec H USA and CAN
- EOS EmoStyle D USA and CAN
- EOS EmoStyle H USA and CAN
- EOS EmoTouch 3 USA and CAN
Minimum Published Firmware
- EmoTec D/H - firmware R4.09 or later
- EmoStyle D/H - firmware R4.09 or later
- EmoTouch 3 - firmware R3.00 or later
- Confirm current firmware before installation
- Update the control when required
Compatibility correction: This product is the remote-connectivity module linked from the EOS Touch 3 product page. The compatible touchscreen control is identified in current EOS documentation as the North American EOS EmoTouch 3 series. Confirm the exact control label and firmware before ordering.
The App Module Is Not a Complete Sauna Control System
This module adds remote connectivity to an already compatible EOS control system. It does not replace the sauna control panel, relay box, power box, temperature sensor, heater, safety equipment, or electrical installation.
Required but Not Included
- Compatible EOS North American control system
- Required control firmware
- Compatible EOS relay box or power box
- Active wired router or network connection
- Standard RJ45 Ethernet cable
- Internet service
- Apple iOS or Android mobile device
- EOS Spa Control App
- Compatible sauna heater and safety components
- Professional installation and configuration
Not Included with This Listing
- Smartphone
- Tablet
- Wi-Fi router
- Ethernet cable
- Mobile data plan
- EOS control panel
- EOS relay box or power box
- Heater safety device
- Sauna heater
- Sauna room
This is not a Wi-Fi module. The App Module connects directly to a router or network access point through a standard wired RJ45 Ethernet cable. The customer's mobile device may connect to the internet through Wi-Fi or mobile data.
Remote Heater Operation Requires an Approved Safety System
Remote operation can energize a sauna heater when the user is not physically beside the cabin. The sauna must be inspected and equipped according to EOS instructions, local code, and the requirements of the installed control and heater system.
Fire-safety requirement: Objects left on or near a sauna heater can ignite. When a heater can be started remotely or by a preset timer, install and configure the protective cover or approved heater safety system required for that installation, such as a compatible rocker-switch system or EOSafe equipment.
Before Remote Start
- Confirm the cabin is empty and ready for operation
- Remove towels and objects from the heater
- Verify the heater guard and safety system
- Confirm ventilation openings are unobstructed
- Check that the sauna door is properly positioned
System Responsibility
- Use only approved EOS components
- Follow the heater and control manuals
- Comply with local electrical and fire codes
- Have the system commissioned by qualified personnel
- Train all operators before enabling remote access
Available Controls Adapt to the Connected Sauna System
The EOS Spa Control App detects the paired control unit and presents the functions supported by that cabin. Not every installation will display every available function.
Finnish Sauna Mode
Monitor actual temperature, adjust the target temperature, select a profile, manage supported lighting, and end the heating process.
Bi-O Sauna Mode
Supported systems may provide temperature and humidity adjustment, vaporizer control, lighting control, profiles, and operating status.
Other Cabin Types
Compatible controls may support selected steam-room, infrared-cabin, Roman-bath, and auxiliary-output functions through the app.
Displayed functions depend on the control model, control firmware, cabin configuration, installed sensors, connected equipment, and enabled outputs. The module does not add hardware functions that are not present in the underlying control system.
Plan the Wired Network Connection Before Installation
Confirm Router Access
Provide a wired Ethernet connection near the relay box or the selected App Module mounting location.
Verify Network Settings
The network must support DHCP and IPv4. Required outbound network communication must not be blocked.
Install and Pair the App
Download the EOS Spa Control App, enter the module MAC address, and complete the guided pairing process.
The published installation requirements identify network port 7250. Confirm that the router, firewall, and managed network permit the communication required by the EOS system.
EOS App Module NA Technical Specifications
| Manufacturer | EOS |
|---|---|
| Product name | EOS App Module NA |
| Technical designation | SBM App NA Module |
| SKU | 14-949081 |
| Item number | 949081 |
| Product type | Remote-connectivity extension module |
| Module dimensions | 2.44 in H x 3.54 in W x 0.71 in D |
| Metric dimensions | 62 mm H x 90 mm W x 18 mm D |
| Housing material | Plastic |
| Mounting | Top-hat rail |
| Sauna control connection | 1 x EOS sauna bus, RJ12 6P6C |
| Network connection | 1 x shielded 10/100 Base-T Ethernet RJ45 jack |
| Power supply | 24V DC through the EOS sauna bus cable |
| Energy consumption | Less than 1W |
| Supported mobile operating systems | Apple iOS and Android |
| IP assignment | DHCP, IPv4 |
| Required network port | 7250 |
| Operating temperature | 14°F to 104°F / -10°C to 40°C |
| Storage temperature | -4°F to 140°F / -20°C to 60°C |
| Installation environment | Indoor installation outside the sauna or wellness cabin |
| Maximum installation altitude | 6,562 ft / 2,000 m |
| Certification | UL certified |
| Manufacturing origin | Made in Germany |
| Published warranty | 2 years |
Technical requirements and app compatibility may change with control firmware, mobile operating-system updates, network configurations, and EOS software releases. Confirm the current system requirements before installation.
What Is Included with the EOS App Module?
Included
- EOS App Module NA
- Pre-mounted EOS sauna bus cable
- Installation and operating instructions
Not Included
- Compatible EOS control unit
- EOS relay box or power box
- RJ45 Ethernet cable
- Router or network switch
- Internet service
- Smartphone or tablet
- Apple or Android device
- Sauna heater
- Remote-start heater safety equipment
- Installation labor
The EOS Spa Control App is required. App availability, compatibility, and mobile operating-system requirements are controlled by EOS and the applicable mobile app marketplace.
Indoor Installation by Qualified Personnel
The module must be installed indoors, outside the sauna, infrared cabin, steam room, or other high-humidity environment. The preferred mounting location is near the compatible relay box or near the network router when the required connections can be completed correctly.
- Disconnect the control system from electrical power
- Confirm the control model and firmware version
- Mount the module securely on a suitable top-hat rail
- Connect the pre-mounted sauna bus cable to a free RJ12 port
- Connect the module to the router with an Ethernet cable
- Protect the module from splash water and condensation
- Do not install the module outdoors
- Do not expose the module to corrosive air or direct sunlight
- Confirm port 7250 is available through the network
- Complete app pairing using the module MAC address
- Test all remote functions and safety devices
Do not open the module housing. Installation, commissioning, repair, and control-system work should be completed by trained personnel using current EOS documentation.
Why Buy the EOS App Module from My Luxury Home Spa?
Authentic EOS Equipment
Shop genuine EOS control panels, remote-access modules, power boxes, heaters, sensors, and system accessories.
Compatibility Assistance
Send us the control model, region, firmware version, and relay-box information when you need help reviewing compatibility.
Clear System Requirements
We identify the network equipment, mobile device, control system, safety equipment, and installation services that are not included.
EOS App Module NA FAQ
What does the EOS App Module do?
It connects a compatible EOS sauna control system to the EOS Spa Control App so supported functions can be monitored and adjusted from an Apple iOS or Android mobile device.
What is the EOS App Module SKU?
The North American EOS App Module is SKU 14-949081.
Is the module compatible with EOS Touch 3?
Current EOS technical documentation lists compatibility with the North American EOS EmoTouch 3 series using firmware R3.00 or later. Confirm the exact control model and firmware before ordering.
Which other EOS controls are compatible?
Published compatibility includes North American EmoTec D/H and EmoStyle D/H controls using firmware R4.09 or later.
Is this a Wi-Fi module?
No. The module connects to the local router or network through a wired RJ45 Ethernet cable.
Is an Ethernet cable included?
No. A standard Ethernet cable is required and sold separately.
Does the module require a separate power supply?
No. It receives 24V DC power through the pre-mounted EOS sauna bus cable.
Is a smartphone or tablet included?
No. The mobile device is not included.
Which mobile operating systems are supported?
EOS identifies Apple iOS and Android as supported mobile operating systems.
Is internet service required?
Yes. Internet access is required for setup and remote access. Network communication must not be blocked by the router or firewall.
Which network port does the module use?
The published installation instructions identify port 7250 as required for the connection.
Can the app start the sauna heater remotely?
Supported systems may allow remote heating control, but the sauna must have the required remote-start safety equipment and must be installed and operated according to current EOS instructions and local requirements.
Does the module add humidity or lighting control?
No. It provides remote access to functions already supported by the connected control system, sensors, and installed equipment.
How many preset profiles are available?
The EOS Spa Control App supports four customizable preset profiles.
Can the module be installed inside the sauna?
No. It must be installed indoors and outside the sauna, steam room, infrared cabin, or other humid wellness cabin.
What comes with the EOS App Module?
The package includes the EOS App Module NA, a pre-mounted sauna bus cable, and installation and operating instructions.
What warranty is published?
Bathing Brands publishes a two-year warranty for the EOS App Module.
Verify Your EOS Control and Firmware
Send us the full control model, North American region designation, current firmware version, relay-box information, and intended network setup when you need help reviewing App Module compatibility.
