Harvia WHP1000M + WHP500M Chimney Extension Package
Extend a compatible Harvia steel chimney with a 1000 mm WHP1000M section and a 500 mm WHP500M section. These insulated modules provide additional length for a planned vertical chimney run in a detached outdoor sauna.
The matching black sections help you adapt a compatible chimney layout to your building. Final height, supports, and roof details depend on the complete installation.
Key Features
Modular Chimney Planning
Two section sizes give you additional options when laying out a compatible Harvia chimney system.
Insulated Construction
A stainless steel smoke pipe and mineral wool insulation form part of Harvia's multi-wall chimney design.
Interlocking Connections
Harvia's rotating joint system secures the sections. Complete the fastening procedure specified in the installation manual.
Declared Performance
The WHP system carries CE marking and declared soot-fire and freeze-thaw resistance under its specified installation conditions.
What's Included
- One Harvia WHP1000M, nominal 1000 mm black extension
- One Harvia WHP500M, nominal 500 mm black extension
- Installation documentation and connection hardware as supplied with the package
Required Components & Compatibility
- Harvia chimney system: Requires a compatible Harvia chimney installation, such as WHP1500M; verify the exact components before purchase.
- Roof and ceiling components: Appropriate rain protection, lead-through parts, and flashing for your roof construction.
- Supports: Additional supports where required by the full chimney layout and installation instructions.
Specifications
| Models | WHP1000M + WHP500M |
|---|---|
| Nominal Section Lengths | 1000 mm + 500 mm; combined 1500 mm (approximately 59.1″) |
| Insulated Component Lengths | 970 mm + 470 mm in Harvia's installation drawing; account for joints when planning installed height |
| Exterior Finishes | Both sections: black powder-coated steel exterior |
| Insulation | Mineral wool |
| Outside Diameter | 220 mm (approximately 8.66″) |
| Smoke Pipe Diameter | 115 mm (approximately 4.53″) |
| Installation Orientation | Vertical only |
| Outdoor Free-Standing Limit | 2 m (approximately 6.6 ft) above the last support |
| Maximum Lateral Support Spacing | 3 m (approximately 9.8 ft), subject to the full installation requirements |
| Maximum System Height | 5 m (approximately 16.4 ft), per Harvia's WHP guidance |
| Certification / Origin | CE-marked WHP system / Made in Finland |
Installation Planning
Confirm the system's suitability for your sauna building and location before purchase. Required termination height depends on the roof, nearby structures, manufacturer instructions, and applicable local requirements.
- Check required termination height, clearances, and supports for your roof and surrounding structures.
- Follow the chimney and stove manuals for component assembly and penetrations.
- Have the complete layout reviewed by a qualified installer.
Pro Tip
Measure from the planned support points and roof penetration before choosing extensions. Share a sketch of your chimney route with your installer so section lengths, joints, and supports can be coordinated.
