Luxury Spas USA | Largo 3-Person Hot Tub
Largo 3-Person Hot Tub With Side-by-Side Loungers
The Luxury Spas Largo 3-Person Hot Tub combines two side-by-side lounge seats with an additional bucket seat. Its 30 adjustable massage jets, 3 HP jet pump, and separate circulation pump bring massage and shared soaking into a rectangular spa layout.
Balboa controls and a 5.5 kW titanium heater support everyday operation. Bluetooth audio, two cushioned neck pillows, underwater lighting, and illuminated waterline, fountain, and step features complete the experience.
Electrical planning: This spa requires a dedicated 240V / 50A GFCI-protected circuit. Have a licensed electrician verify the wiring diagram, connection requirements, and local code for the unit supplied.
Who Is the Largo Best For?
The Largo is worth comparing if two regular bathers want side-by-side loungers, with a bucket seat available for a third person. Its separate circulation pump, Bluetooth audio, and multiple lighting features suit buyers who want a well-equipped three-person spa.
This is the standard 240V Largo. Choose it when permanent electrical service fits your plans, and compare the Largo Hybrid separately if 120V plug-and-play operation is your priority.
Two Loungers Plus a Bucket Seat
The Largo places two lounge seats beside one another and adds a bucket seat for a third bather. That combination gives couples a shared reclining arrangement while retaining an alternative seated position for guests or a change of posture.
Compare the lounge contours, legroom, and jet locations against your preferred soaking position. The supplier's three-person rating describes capacity; comfort depends on body size and how the positions are used.
If you prefer mostly upright seating or regularly invite a larger group, compare other layouts before choosing. For a tighter patio, the cabinet dimensions matter as much as the advertised seat count.
Dual Loungers, Massage & Lighting
Two Lounge Seats
Side-by-side loungers offer shared reclining comfort, with a bucket seat providing an additional position for a third bather.
30 Adjustable Jets
A 3 HP jet pump serves the massage system, with adjustable jets positioned for the back, legs, and feet.
Separate Circulation
A dedicated circulation pump moves water through filtration independently of the main jet pump. Hydrozone ozonation supplements routine water care.
Light & Sound
Bluetooth audio pairs with color-changing underwater lighting, LED step lights, fountain lights, and waterline lighting.
Product Specifications
| Brand / Model | Luxury Spas USA / Largo |
|---|---|
| Seating Capacity | Up to 3 adults |
| Seating Layout | 2 side-by-side lounge seats and 1 bucket seat |
| Exterior Dimensions | 83″ L × 63″ W × 31″ H, per the current supplier listing |
| Massage Jets | 30 adjustable jets |
| Jet Pump | 3 HP |
| Circulation | Separate circulation pump |
| Heater | 5.5 kW titanium |
| Controls | Balboa operating system |
| Electrical Requirement | Dedicated 240V / 50A GFCI-protected circuit |
| Listed System Power | 7,350 W |
| Lighting | Color-changing underwater lighting; LED step, fountain, and waterline lights |
| Audio | Bluetooth sound system |
| Neck Pillows | 2 cushioned pillows |
| Water Care | Hydrozone ozonator and filtration system |
| Insulation | Multi-layer foam insulation |
| Included Accessories | UV-rated insulated spa cover and steps |
Confirm the supplied unit's dimensions before preparing a foundation or finalizing delivery access. Seating capacity is the supplier's rating; comfort varies with bather size and position. Listed wattage is not a constant operating draw or a daily energy-cost estimate.
Largo vs. Riley: Compare Two Lounge-Focused Spas
Both models are rated for three adults and include two lounge positions. The Riley has a smaller exterior footprint, while the Largo adds a separate circulation pump and a broader lighting package.
| Feature | Largo | Riley Studio Series |
|---|---|---|
| Rated capacity | 3 adults | 3 adults |
| Seating layout | 2 side-by-side loungers and 1 bucket seat | Includes 2 lounge seats |
| Exterior dimensions | 83″ × 63″ × 31″ | 77″ × 52″ × 31″ |
| Massage jets | 30 adjustable jets | 26 jets |
| Jet pump | 3 HP | 3 HP multi-speed |
| Heater | 5.5 kW titanium | 5.5 kW titanium |
| Electrical service | Dedicated 240V / 50A | Dedicated 240V / 50A |
Scroll horizontally on smaller screens. Jet count and horsepower alone do not determine massage comfort or intensity.
Browse our Medium Hot Tubs Collection for additional seating options. Our Hot Tub Buying Guide explains how to compare layout, equipment, and installation needs.
Optional Wi-Fi Control
A compatible plug-in Wi-Fi adapter may be available for $350 through a custom quote. This option is arranged with our team rather than added through the cart. We confirm control-system compatibility and supported app functions during quoting.
What's Included
- Largo spa with installed massage jets, 3 HP jet pump, and separate circulation pump
- Balboa controls and 5.5 kW titanium heater
- Bluetooth audio, underwater, step, fountain, and waterline lighting, and two cushioned neck pillows
- Hydrozone ozonator and filtration system
- UV-rated insulated spa cover and steps
The optional Wi-Fi adapter is quoted separately.
How Much Space Does the Largo Need?
The current supplier listing gives exterior dimensions of 83 inches long, 63 inches wide, and 31 inches high. That is a cabinet footprint of approximately 6 feet 11 inches by 5 feet 3 inches, before allowing for steps, cover operation, and service access.
Older supplier details have also listed an 85-inch length. Confirm the dimensions of the exact unit being supplied before pouring a pad or arranging a tight delivery route. Exterior height does not measure water depth or usable seat depth.
Confirm equipment-panel locations and any clearance required by a separately selected cover lifter. Have a qualified professional assess decks or elevated installations using the complete spa, water, and occupant load. Indoor projects also need drainage, ventilation, humidity control, and electrical planning.
Prepare Your Site & Delivery Route
- Foundation: Provide a solid, level base rated for the spa, water, and occupants. Have a qualified professional assess any deck or elevated installation.
- Clearance: Allow room for equipment servicing, cover operation, and safe entry and exit. Confirm service-panel locations before placement.
- Access: Measure gates, turns, slopes, steps, and overhead obstructions. Request packaged dimensions and handling requirements when assessing a tight route.
- Electrical: Have a licensed electrician follow the instructions for the exact spa and control system supplied.
Review our Hot Tub Installation Guide and Electrical Planning Guide.
Circulation, Water Care & Running Costs
Follow the owner's manual for water testing, sanitizer levels, filter cleaning, and water changes. Ozone and filtration supplement routine sanitizer and water balancing. Keep the cover secured between sessions and follow the manufacturer's cold-weather operating or winterization instructions.
The separate circulation pump supports filtration independently of the main massage pump. Use the instructions for the supplied Balboa system to set operating modes and filtration schedules. Keep filters clean and maintain sanitizer levels even when the ozonator is operating.
Running costs depend on climate, utility rates, water temperature, cover use, and bathing frequency. Budget for electricity, treatment supplies, replacement filters, and servicing. Multi-layer foam insulation and the included cover help retain heat; the 7,350 W system listing is not a constant power draw or daily cost estimate.
Shipping & Placement
Standard curbside freight delivery within the contiguous United States is included. Contact us for current processing and transit estimates and any access requirements.
The customer arranges movement from curbside to the installation location. White Glove assistance may be available in select areas; backyard placement, stairs, and crane service require separate arrangements and a confirmed quote before ordering.
Inspect the shipment at delivery and record visible damage with the carrier before signing. Send us your ZIP code and access details for delivery planning.
Manual & Warranty Information
Luxury Spas USA advertises a 10-year structural warranty. Request the current certificate applicable to your order for coverage, parts and labor provisions, eligibility, and exclusions.
Request the installation manual for the Largo and its supplied control system before scheduling electrical work. The Studio Series Manual is a general ownership reference; confirm that its instructions apply to your unit before using it for wiring or startup.
Request Largo documentation and order-specific warranty terms .
Largo Hot Tub FAQs
How many people does the Largo seat?
It is rated for up to three adults, with two side-by-side lounge seats and a bucket seat. Comfort varies with bather size and seating position.
Does the Largo have two loungers?
Yes. Two side-by-side loungers provide reclining positions, while the bucket seat offers an additional seated position.
How many jets does the standard Largo have?
The standard Largo has 30 adjustable massage jets powered by a 3 HP jet pump. A separate circulation pump supports filtration.
What dimensions should I use for planning?
The current supplier listing gives 83 inches long by 63 inches wide by 31 inches high. Confirm the supplied unit before preparing a pad or arranging tight access, because older supplier details have also listed an 85-inch length.
Is this Largo a plug-and-play hot tub?
No. This is the standard 240V model, requiring a dedicated 50A GFCI-protected circuit installed by a licensed electrician. The Largo Hybrid is a separate configuration.
Are Bluetooth audio and lighting included?
Yes. The Largo includes Bluetooth audio, color-changing underwater lighting, and LED step, fountain, and waterline lights. Two cushioned neck pillows are also included.
Are the cover and steps included?
Yes. A UV-rated insulated spa cover and steps are included. The optional Wi-Fi adapter, if compatible, is quoted separately.
Can I add Wi-Fi control?
A compatible plug-in adapter may be available for $350 through a custom quote. Contact us to confirm compatibility, availability, and supported functions before ordering.
Does delivery include final placement?
Standard freight service is curbside. Movement to the installation site requires a separate plan. Send us your ZIP code and access details to ask about available quoted placement assistance.
